Komponente PC, Power Supply
PSU 500W 80+ WHITE EVGA W2
Gjendja:
Ka stok
PSU 500W 80+ WHITE EVGA W2
About this item
- An Ultra-Quiet 120mm Fan
- Provides up to 40A/480W on the +12V rail
- Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OPP (Over Power Protection), and SCP (Short Circuit Protection)
- 80 PLUS White certified, with 85% efficiency or higher under typical loads
7,500 L
Ka stok
PSU 500W 80+ WHITE EVGA W2
About this item
- An Ultra-Quiet 120mm Fan
- Provides up to 40A/480W on the +12V rail
- Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OPP (Over Power Protection), and SCP (Short Circuit Protection)
- 80 PLUS White certified, with 85% efficiency or higher under typical loads
CABLE LENGTH
| ATX Cable | 1x 550mm |
| EPS Cable | 1x 600mm |
| PCIE Cable | 1x 550mm, 670mm |
| SATA Cable | 2x 450mm, 570mm, 690mm |
| Four-Pin Peripheral Cable | 1x 450mm, 570mm, 690mm, 810mm(f) |
| AC Power | 1x 1200mm |
| Modular Cable Type | No |
CONNECTOR QUANTITY
| 24 Pin ATX | 1x 24pin (20+4) |
| EPS (CPU) | 1x 8pin (4+4) |
| PCIE | 2x 8pin (6+2) |
| SATA | 6x |
| Four-Pin Peripheral | 3x |
| Floppy | 1x |
POWER SPECS
| AC Input | 200-240V~, 3.5A, 60/50 Hz | ||||
| Rail | +3.3V | +5V | +12V | +5Vsb | -12V |
| Max Output | 18A | 18A | 40A | 3A | 0.3A |
| 130W | 480W | 15W | 3.6W | ||
| Total | 500W | ||||
ADDITIONAL DETAILS
| Operating Temperature | 0° to 40° C |
| Japanese Capacitors | No |
| ECO Mode | No |
| MTBF | 100,000 Hours |
| Net Weight | 4 lbs |
| Size | 85mm (H) x 150mm (W) x 140mm (L) |
| Approvals | TUV, CB, CE, RCM, CCC, RoHS Compliance with ErP Lot 3 2014 Requirement |
| Fan Size / Bearing | 120mm Sleeve Bearing |
