Form factor M.2 2280
Interface PCIe 4.0 NVMe
Controller Phison E18
NAND 3D TLC
Sequential read/write1 1TB – 7,300/6,000MB/s
Random 4K read/write1 500GB – up to 450,000/900,000 IOPS
1TB – up to 900,000/1,000,000 IOPS
Operating Tempetemperaturerature 0°C~70°C
Dimensions 80mm x 22mm x 2.21mm (500GB-1TB)
80mm x 22mm x 3.5mm (2TB-4TB)
Weight 500GB-1TB – 7g
2TB-4TB – 9.7g
Vibration operating 2.17G peak (7-800Hz)
Vibration non-operating 20G peak (20-1000Hz)
MTBF 1,800,000 hours
